Digital Flatbed UV Inkjet Printer for PCB Board Leather Scutcheon

1SET
MOQ
Negotiable
Price
Digital Flatbed UV Inkjet Printer for PCB Board Leather Scutcheon
Features Gallery Product Description Request A Quote
Features
Specifications
Inks Color: C, M, Y, K, LC, LM, W
RIP: Texprint, Seeget, PhotoPrint
Print Head: Xaar 1201 / RICOH G5i
Print Format: PDF, PS, EPS, TIFF, AL Etc
Condition: New
Warranty: One Year
Head Quantity: 2-8 Heads
High Light:

Cylindrical UV Inkjet Printer

,

PE Bottle UV Inkjet Printer

,

MDF Board UV Inkjet Printer

Basic Infomation
Place of Origin: CHINA
Brand Name: ECOOGRAPHIX
Certification: CE
Model Number: Ecoo-1216
Payment & Shipping Terms
Packaging Details: Standard export packing
Delivery Time: about 20days
Payment Terms: L/C, T/T
Supply Ability: 300SET
Product Description

Digital Flatbed UV Inkjet Printer for PCB Board Leather Scutcheon



 Ecoo KGT-1216 type UV printer adopts Xaar 1201/Ricoh gen5i nozzle (optional), equipped with the latest high spray board card and special wave curve, which can easily print toys, handicrafts and vamp with uneven high drop. It is widly used to print on glass, ceramic tile, PVC, aluminum sheet, wood, MDF board, metal panel, billboard,
acrylic panel, paper board, foam board, PVC expansion board, corrugated cardboard, bamboo, leather, bottle, cup, USB etc;
and for flexible materials such as PVC, canvas, leather etc.



Specification



Flatbed UV Printer Machine
Model Ecoo KGT-1216
Print Head Xaar 1201 / RICOH G5i
Head Quantity Maximum 8 heads
Print Technology Variable dot printing
Resolution 720dpi*900dpi / 720dpi*1200dpi
Control system Digital inkjet system
Negative Pressure System Self made negative pressure system
Printing height 0-120mm
Software interface Colorgate/Photoprint
Motor Resal servo motor
Platform Optical fiber data transmission
Curving way UV curving
Lift way Ink car lifting+automatic height detection
Movement way Single Y-axis electric drive
Ink type UV environmental friendly ink ( VOC free)
The ink color C, M, Y, K, LC, LM, W
Ink supply system Drive pump for ink supply
Dimension 2104x2300x1185mm
Net weight 500KG
Curving way Temperature:25-35°C, Humidity:50%-80%
Power AC220V 5000W
Speed
Pass 6pass 8pass
Feather Weak Medium Strong Weak Medium strong
Speed(m2/h) 8.38 7.15 5.20 6.53 5.60 4.00



Print materials:

Digital Flatbed UV Inkjet Printer for PCB Board Leather Scutcheon 0

Digital Flatbed UV Inkjet Printer for PCB Board Leather Scutcheon 1





Digital Flatbed UV Inkjet Printer for PCB Board Leather Scutcheon 2

Digital Flatbed UV Inkjet Printer for PCB Board Leather Scutcheon 3

Packing and Delivery:

Digital Flatbed UV Inkjet Printer for PCB Board Leather Scutcheon 4
