1650mm Carton Die Cutting and Stripping Machine

1SET
MOQ
Negotiable
Price
1650mm Carton Die Cutting and Stripping Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Max. Sheet Size(mm): 1670 X 1210
Warranty: One Year
Max. Die Cutting Size(mm): 1650*1200mm
Min.gripper Margin(mm): 7mm
Condition: New
 Feeding Pile Height(mm): 300
Weight: 27Ton
Turntable Size: Diameter:2550mm Height:85mm
High Light:

Recyclable Pallet Wrapping Machine

,

500mm Pallet Wrapping Machine

,

12rpm Turntable Pallet Wrapping Machine

Basic Infomation
Place of Origin: CHINA
Brand Name: ECOOGRAPHIX
Certification: CE
Model Number: ECOO1650VQ
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 30DAYS
Payment Terms: L/C, T/T
Supply Ability: 500SETS
Product Description



Automatic Flat-bed Carton Die Cutting Machine with Waste Stripping



Features:

1,Complete design, accurate installation, high stability, high security, low noise.

2,High strength gripper, advanced gripper device can apply all kinds of corrugated paper. Positioning device ensure the cutting precision.

3,Worm, worm gear and special designed crankshaft connecting device is linked by bearing bush, reduce the movement clearance, avoid impact between worm and worm gear. Run steadily, high cutting pressure. It has a function of high point pressure hold. Worm gear is made of high wear-resisting aluminum bronze, it has long durability.

4,Non-stop feeding and delivery device can shorten the auxiliary time, improve the efficiency.

5,Adopt advance cam mechanism, pressure adjusting device, pneumatic die locking, pneumatic sampling, overload protection device. Adopt imported high precision chain, imported pneumatic clutch.

6,Adopt lead edge feeding, apply secondary positioning mechanism, lower the requirement about paper. During the process, keep the workers hands far away from the cutting section, ensure the safety.

7,Pneumatic die locking mechanism makes changing of die, makeready more convenient, die frame fix firmer, more accurate, time saving.

8,Programmable controller and man-machine interface. Digital display the working speed, processing umber, total running time. The display of trouble makes trouble shooting more convenient. Automatic control and real time monitor feeding, cutting and delivery parts, cooperate with the safety device in each part. Make the operation more reliable, machine adjustment and trouble shooting more convenient.

9,High precision intermittent mechanism, high cutting precision, running steadily.

10,Automatic paper delivery, arranging device makes delivery more convenient and neat.

11,Floating function of cutting die plate make inserting and pulling out the plate more convenient

12,Double sheet, crooked sheet, empty sheet optoelectronic detecting device, ensure the paper in the right position, reduce waste.

13,Electronic control module design, adopt imported electronic components, ensure the accuracy and reliability.

14,Cycling cooling oil supply system ensure the movement parts get adequately lubricated to ensure the durability.

15,Imported pneumatic clutch, joint and withdraw conveniently, with small brake angle, it can transmit high torque.

16,Front and rear cutting pressure can be adjust separately, manual wheel makes it convenient.

17,Adopt fixed quantity at fixed timing oil supply system, ensure the movement parts get adequately lubricated to let better durability.

18,3 waste stripping frames work together, human-friendly design, easy to install and uninstall the waste stripping plate.

19,Automatic waste stripping device can remove the waste easily.

20,Full side stripping is optional.

21,Non-stop delivery conveyor is optional.






Technical Specifications:



Model Ecoo-1650VQ
Max. Sheet size(mm) 1670 x 1210
Min. Sheet size(mm) 520 x 460
Max. Die cutting size(mm) 1650 x 1200
Inside chase size(mm) 1660*1215
Cutting plate size 1680*1186
Min.gripper margin(mm) 7
Die cutting accuracy(mm) ≤±0.25
Max.pressure(T) 300
Max.machine speed(s/h) 4500
Feeding pile height(mm) 300
Delivery pile height(mm) 1300
Stock range corrugated paper: 9 mm
Power 22 KW
Dimension(mm) 8200(+2300)*3200(+2300)*2550
Weight(T) 27 T
