600x520mm EcooGraphix Automatic Paper Box Window Patching Machine
~~~◑ Specifictions ◐~~~
Model RT-600
Max. sheet size 600*520mm
Min. sheet size 100*80mm
Max. window size 400*400mm
Min. window size 45*30mm
Paper thickness Cardboard 200-2000g/m2 ; Corrugated board: from micro-flute-6mm thickness
Film thickness 0.03-0.2um
Stickup accuracy (left/right)±0.5mm, (top/bottom)±1mm
Machine size(L*W*H) 4500*1500*1700mm
Net weight 3300kg
Main power 3kw
Sizing roller power 0.09kw
Delivery stacker power 0.37kw
| Model | RT-600 |
| Max. sheet size | 600*520mm |
| Min. sheet size | 100*80mm |
| Max. window size | 400*400mm |
| Min. window size | 45*30mm |
| Paper thickness |
Cardboard 200-2000g/m2; Corrugated board: from micro-flute-6mm thickness |
| Film thickness | 0.03-0.2um |
| Stickup accuracy | (left/right)±0.5mm, (top/bottom)±1mm |
| Machine size(L*W*H) | 4500*1500*1700mm |
| Net weight | 3300kg |
| Main power | 3kw |
| Sizing roller power | 0.09kw |
| Delivery stacker power | 0.37kw |
~~~◑ Details ◐~~~
 |
|
|
|
|
|
~~~◑ Producing And Packaging ◐~~~
From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.
~~~◑ Certificates ◐~~~
~~~◑ FAQ ◐~~~
Q1: What are your main products ?
A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment and so on.
You can get the equipment and consumables all in one and no worry about the after-sales service from our company.
Q2: Where is your factory ?
A: Our CTP Processor machine factory is in Shanghai, you are warmly welcome to visit our factory!
Q3: What is your warranty for the CTPs ?
A: Three years' Laser Head and main spare parts for the CTPs, one year for the Processor. If the customer uses EcooGraphix CTP plate with the CTP machine, we will provide the Lifetime Warranty.
Q4: Can you also supply the Workflow and RIP ?
A: Yes, we can provide the Workflow Brainnew and RIP Compose V12.
Q5: What about the installation and after-sales technician support ?
A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.
These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.
