ISO Flexo Corrugated Paper Pigment Offset Printing Ink
Send Message

ISO Flexo Corrugated Paper Pigment Offset Printing Ink

1kg
MOQ
Negotiable
Price
ISO Flexo Corrugated Paper Pigment Offset Printing Ink
Features Gallery Product Description Request A Quote
Features
Specifications
Packing: 20kg/Plastic Bucket
Main Component: Pigment
One Set Colors: Cyan,Megenta,Yellow,Black
Certificates: ISO,ROHS,REACH,ASTM,CPSIA,SGS
HS Code: 321519
Application: Corrugated Carton Various Paper
PH Value: 7.5-8.5
Net Weight: 20KGS
High Light:

Pigment Offset Printing Ink

,

Flexo Corrugated Offset Printing Ink

,

ROHS Offset Printing Ink

Basic Infomation
Place of Origin: CHINA
Brand Name: ECOOGRAPHIX
Certification: ISO,ROHS,REACH,ASTM,CPSIA,SGS
Model Number: ECOO-SFH
Payment & Shipping Terms
Packaging Details: standard export packing
Delivery Time: 15days
Payment Terms: T/T
Supply Ability: 500,00Tons
Product Description

Flexo Corrugated Carton Paper Printing Ink

Fast Drying,Environmental Friendly


Features

This series of products have the characteristics of high color concentration, bright color, fast drying, good abrasion resistance and water resistance, especially suitable for high-speed carton printing machine.



Application

Suitable for printing on various papers Corrugated Carton.



Parameter

 Viscosity: 15 ± 5 seconds (Chai's 4 # cup, customize)

 Fineness: ≤ 5-8 μ

PH value: 7.5 ~ 8.5



Technology

Use it directly.Stir well before use. In general, it is recommended to use the original ink.After printing, the machine should be washed immediately with water to avoid drying.After drying, the machine should be washed with machine water.



Package and specification

Plastic bucket packaging. Net weight 20kg



Storage

This product should be stored in a closed container, indoor storage, avoid freezing, exposure and high temperature.


3. Specification

Type ECOO-INK-F
Printing speed 8,000rph-10,000rph
Packing 1 kg/2.5 kg per tin, 12tins/ 6 tins per carton
Shelf Life 3 years (from the production date); product against light and water
Appearance Colored paste



Application

ECOO-IN-F printing ink is suitable for printing packaging, advertisement, label, brochures and decorating products on art paper, coated paper, offset paper, cardboard, etc., especially suitable for single-color and multi-color printing.
ITEM/TYPE

TACK

VALUE

FLUIDITY

(mm)

PARTICLE

SIZE (μm)

SETTING

TIME (min)

DRYING

TIME (hr)

SKINNING

TIME (hr)

YELLOW 6-7

35±1



15 4 < 10 >15
MAGENTA 5.5-6.5

34±1



15 4 < 10 >15
CYAN 6.5-7.5

35±1



15 4 < 10 >15

F

BLACK

7-8

35±1



15 4 < 10 >15



Tack Value The value is measured in 1 minute by inkometer at 32℃ and 400rpm.
Set Time Printing adapter, 157g art paper, the volume of ink-coating can be up to 0.125cc
Condition of test Room temperature 25℃, humidity 65%-75%
ITEM/TYPE

Light

Resistance

Heat

Resistance

Acid

Resistance

Alkaline

Resistance

Alcohol

Resistance

Soap

Resistance

F

YELLOW

4 5 5 4 4 4

F

MAGENTA

3 5 5 5 4 5

F

CYAN

7 5 5 5 5 5

F

BLACK

7 5 5 5 5 5
Light Fastness 1-8 (weak-strong)
Others 1-5 (weak-strong)



4. Composition and related information



Hazards identification

· General information: This product is not dangerous.

· Hazard description: Not applicable.

· Information concerning particular hazards for human and environment:

The product has to be labelled due to the calculation procedure of the "General Classification guideline for

chemicals of 67/548/EEC and 1999/45/EC" as well as 1272/2008/EC in the latest valid version.

· Classification system:

The classification is according to the latest editions of the EU-lists, and extended by company and literature

data.

· GHS label elements:

Not applicable



ISO Flexo Corrugated Paper Pigment Offset Printing Ink 0

ISO Flexo Corrugated Paper Pigment Offset Printing Ink 1



ISO Flexo Corrugated Paper Pigment Offset Printing Ink 2

ISO Flexo Corrugated Paper Pigment Offset Printing Ink 3

ISO Flexo Corrugated Paper Pigment Offset Printing Ink 4



ISO Flexo Corrugated Paper Pigment Offset Printing Ink 5


FAQ:
1. What are your main products ?

EcooGraphix is a leading and professional Supplier for Prepress Solution , Printing Materials and Post Packing Equipment.

Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP , CTCP , VLF CTP and CTCP, Flexo CTP , Processor , Offset Plates ,Printing inks ,Printing blankets , postpress Packing equipments and so on.
 Our partners in USA,Canada,Mexico,Colombia,Turkey,Hungary,South Africa and so on are very pleased with our Technician Support service and product performance.

You can get the prepress equipment and consumables all in one and no worry about the after-sales service from our company.
