Flexo Corrugated Carton Paper Printing Ink
Fast Drying,Environmental Friendly
Features
This series of products have the characteristics of high color concentration, bright color, fast drying, good abrasion resistance and water resistance, especially suitable for high-speed carton printing machine.
Application
Suitable for printing on various papers Corrugated Carton.
Parameter
Viscosity: 15 ± 5 seconds (Chai's 4 # cup, customize)
Fineness: ≤ 5-8 μ
PH value: 7.5 ~ 8.5
Technology
Use it directly.Stir well before use. In general, it is recommended to use the original ink.After printing, the machine should be washed immediately with water to avoid drying.After drying, the machine should be washed with machine water.
Package and specification
Plastic bucket packaging. Net weight 20kg
Storage
This product should be stored in a closed container, indoor storage, avoid freezing, exposure and high temperature.
3. Specification
| Type | ECOO-INK-F |
| Printing speed | 8,000rph-10,000rph |
| Packing | 1 kg/2.5 kg per tin, 12tins/ 6 tins per carton |
| Shelf Life | 3 years (from the production date); product against light and water |
| Appearance | Colored paste |
|
Application |
ECOO-IN-F printing ink is suitable for printing packaging, advertisement, label, brochures and decorating products on art paper, coated paper, offset paper, cardboard, etc., especially suitable for single-color and multi-color printing. |
| ITEM/TYPE |
TACK VALUE |
FLUIDITY (mm) |
PARTICLE SIZE (μm) |
SETTING TIME (min) |
DRYING TIME (hr) |
SKINNING TIME (hr) |
| YELLOW | 6-7 |
35±1
|
15 | 4 | < 10 | >15 |
| MAGENTA | 5.5-6.5 |
34±1
|
15 | 4 | < 10 | >15 |
| CYAN | 6.5-7.5 |
35±1
|
15 | 4 | < 10 | >15 |
|
F BLACK |
7-8 |
35±1
|
15 | 4 | < 10 | >15 |
| Tack Value | The value is measured in 1 minute by inkometer at 32℃ and 400rpm. | |||||
| Set Time | Printing adapter, 157g art paper, the volume of ink-coating can be up to 0.125cc | |||||
| Condition of test | Room temperature 25℃, humidity 65%-75% | |||||
| ITEM/TYPE |
Light Resistance |
Heat Resistance |
Acid Resistance |
Alkaline Resistance |
Alcohol Resistance |
Soap Resistance |
|
F YELLOW |
4 | 5 | 5 | 4 | 4 | 4 |
|
F MAGENTA |
3 | 5 | 5 | 5 | 4 | 5 |
|
F CYAN |
7 | 5 | 5 | 5 | 5 | 5 |
|
F BLACK |
7 | 5 | 5 | 5 | 5 | 5 |
| Light Fastness | 1-8 (weak-strong) | |||||
| Others | 1-5 (weak-strong) | |||||
4. Composition and related information
Hazards identification
· General information: This product is not dangerous.
· Hazard description: Not applicable.
· Information concerning particular hazards for human and environment:
The product has to be labelled due to the calculation procedure of the "General Classification guideline for
chemicals of 67/548/EEC and 1999/45/EC" as well as 1272/2008/EC in the latest valid version.
· Classification system:
The classification is according to the latest editions of the EU-lists, and extended by company and literature
data.
· GHS label elements:
Not applicable
FAQ:
1. What are your main products ?
EcooGraphix is a leading and professional Supplier for Prepress Solution , Printing Materials and Post Packing Equipment.
Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP , CTCP , VLF CTP and CTCP, Flexo CTP , Processor , Offset Plates ,Printing inks ,Printing blankets , postpress Packing equipments and so on.
Our partners in USA,Canada,Mexico,Colombia,Turkey,Hungary,South Africa and so on are very pleased with our Technician Support service and product performance.
You can get the prepress equipment and consumables all in one and no worry about the after-sales service from our company.
