Digital LED UV Varnish for Label Printing
Fast Drying,Environmental Friendly
Features
This series of products have the characteristics of high color concentration, bright color, fast drying, good abrasion resistance and water resistance, especially suitable for high-speed carton printing machine.
Application
Suitable for printing on various papers or PP film,metalized materials of roll labels.
Parameter
Viscosity: 15 ± 5 seconds (Chai's 4 # cup, customize)
Fineness: ≤ 5-8 μ
PH value: 7.5 ~ 8.5
Technology
Use it directly.Stir well before use. In general, it is recommended to use the original ink.After printing, the machine should be washed immediately with water to avoid drying.After drying, the machine should be washed with machine water.
Package and specification
Plastic bucket packaging. Net weight 20kg
Storage
This product should be stored in a closed container, indoor storage, avoid freezing, exposure and high temperature.
3. Specification
| Type |
ECOO-INK-Varnish |
| Printing speed |
50m/min |
| Packing |
5kg per bottle |
| Shelf Life |
3 years (from the production date); product against light and water |
| Appearance |
Colored paste |
|
Application
|
ECOO-IN-F printing ink is suitable for printing label, stickers,tooth paste tube products on art paper, coated paper, PP film, etc., especially suitable for single-color varnish or cold foil. |
| ITEM/TYPE |
TACK
VALUE
|
FLUIDITY
(mm)
|
PARTICLE
SIZE (μm)
|
SETTING
TIME (min)
|
DRYING
TIME (hr)
|
SKINNING
TIME (hr)
|
| YELLOW |
6-7 |
35±1
|
15 |
4 |
< 10 |
>15 |
| MAGENTA |
5.5-6.5 |
34±1
|
15 |
4 |
< 10 |
>15 |
| CYAN |
6.5-7.5 |
35±1
|
15 |
4 |
< 10 |
>15 |
|
F
BLACK
|
7-8 |
35±1
|
15 |
4 |
< 10 |
>15 |
| Tack Value |
The value is measured in 1 minute by inkometer at 32℃ and 400rpm. |
| Set Time |
Printing adapter, 157g art paper, the volume of ink-coating can be up to 0.125cc |
| Condition of test |
Room temperature 25℃, humidity 65%-75% |
| ITEM/TYPE |
Light
Resistance
|
Heat
Resistance
|
Acid
Resistance
|
Alkaline
Resistance
|
Alcohol
Resistance
|
Soap
Resistance
|
|
F
YELLOW
|
4 |
5 |
5 |
4 |
4 |
4 |
|
F
MAGENTA
|
3 |
5 |
5 |
5 |
4 |
5 |
|
F
CYAN
|
7 |
5 |
5 |
5 |
5 |
5 |
|
F
BLACK
|
7 |
5 |
5 |
5 |
5 |
5 |
| Light Fastness |
1-8 (weak-strong) |
| Others |
1-5 (weak-strong) |
4. Composition and related information
Hazards identification
· General information: This product is not dangerous.
· Hazard description: Not applicable.
· Information concerning particular hazards for human and environment:
The product has to be labelled due to the calculation procedure of the "General Classification guideline for
chemicals of 67/548/EEC and 1999/45/EC" as well as 1272/2008/EC in the latest valid version.
· Classification system:
The classification is according to the latest editions of the EU-lists, and extended by company and literature
data.
· GHS label elements:
Not applicable
