450GSM Paper 450SQM/H Flatbed Inkjet Printer With 6 Printheads

1SET
MOQ
Negotiable
Price
450GSM Paper 450SQM/H Flatbed Inkjet Printer With 6 Printheads
Features Gallery Product Description Request A Quote
Features
Specifications
Printhead Quantity: 6 Pieces
Feeding Width: 1080mm
Printhead Model E Flaps: Epson
Printing Efficiency: 450m2/hour
Voltage: 380V/50HZ
Packing: 3500x1350x2000mm(L X W X H)
Gross Weight: 1800KGS
Warranty: One Year
Materials: Paper 280-450GSM
HS Code: 844140
Power Supplier: ≤ 1.7KW , AC 220V±10%,50-60Hz
Highlight:

450SQM/H Flatbed Inkjet Printer

,

6 Printheads Flatbed Inkjet Printer

,

450GSM Paper Flatbed Inkjet Printer

Basic Infomation
Place of Origin: CHINA
Brand Name: ECOOGRAPHIX
Certification: CE
Model Number: 1086AF
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 30DAYS
Payment Terms: L/C, T/T
Supply Ability: 500SETS
Product Description

Corrugated Paper Flatbed Digital Inkjet Printer Epson Print Heads 450SQM Per Hour



  ◆ intelligent jump white function: large format large blank area automatically jump white jet printing, production more efficient
◆ no energy consumption Paper feeding system: paper delivery smooth format 1080 × ≦ 1500mm manual single sheet can be longer paper, cardboard stacking by the size of the board size, flatness, strength, thickness
◆ intelligent paper detection system: automatic detection of paper and its thickness, intelligent adjustment car height
◆ automatic maintenance of the nozzle: the software has a nozzle automatic flash spray maintenance function to ensure that the nozzle is smooth
◆ With corrosion-resistant all-metal ink supply channel Industrial grade nozzle: with 1280 nozzles with 600dpi high resolution, nozzle life of up to 100 billion times, up to eight gray color; nozzle comes with positioning pin, Easy installation and maintenance, fast inside the nozzle can be heated to 60 degrees, can adapt to different ambient temperature and ink viscosity
◆ reliable PCI communication: the use of high-speed and stable industrial-grade PCI interface all-fiber data communication mode
◆ simple printing debugging: the use of advanced nozzle switch control and feather technology, easy to complete the printing overlay adjustment. So that the printing effect is more perfect
◆ order of intelligent order: the customer free to set the order of continuous production of different orders and in accordance with the order of automatic production, the middle of the operator does not need another row to achieve 3 seconds quick for a single, more time and effort
◆ equipment in line with CE standards and human industrial design requirements





Digital Corrugated Printer
Model Ecoo-1806AF
Printhead quantity 6 pieces
Feeding width 1800mm
Printing area Max 1800mm*1500mm , Min 600*350mm
Color type C,M,Y,K
Printhead model Mico-piezo Epson printing head
Temperature control Integrated heater and thermistor
Printhead life 100 billion actuations per nozzle
Printing efficiency Up to 450 m2/hour
Printing resolution ≥360*600 dpi
Controlled ink dot size 7~35pl
Jetting frequency 30KHz
Corrugated thickness Between 1mm~20mm
Feeding mode Automatic feeding
Graphics Format Support JPG,BMP,TIF
Printing head Corrosion-resistant industrial ink jet head
Control system Digital-printing control system from LeiPeng intelligent Technology
Ink-provide Automatic two levels supply, Fully enclosed ink supply channel

Print head cleaning

system

Automatic Negative pressure suction
Work environment 15-30℃ indoor, temperature , Humidity 20-70%
Press roll method Electrical control
Warranty 6 months for the print head, 1 year for the machine
Operate system Windows 7 system 64-bit operating system
Power supply ≤ 4.7KW , AC 220V±10%,50-60Hz
Machine size 3500*3500*1580mm
Packing size 3700*3700*1900mm
Weight Net weight: 1800KG



MACHINE CONFIGURATION LIST:

Product name Main parts specification quantity manufacturers producing area
Printing system Printing head Epson 6 Epson Japan
Color software   1 Ultriaprint China
Moving parts X servo motor 0.75KW 1 PANASONIC Japan

feeding servo

motor

0.75KW 1 PANASONIC Japan
Z servo motor 86 series 1 MOONS China

Transmission

part

X guide rail 20 2 WON/ABBA Korea/Japan
Control system PLC XC3 series 1 Xinje China
Touch panel   1 PaneMaster China
Computer     Lenovo China
Printing software   1 Sinlopon China
UV light part UV light   2   China
UV Chiller 3000W 1   China





450GSM Paper 450SQM/H Flatbed Inkjet Printer With 6 Printheads 0







450GSM Paper 450SQM/H Flatbed Inkjet Printer With 6 Printheads 1

450GSM Paper 450SQM/H Flatbed Inkjet Printer With 6 Printheads 2

450GSM Paper 450SQM/H Flatbed Inkjet Printer With 6 Printheads 3

450GSM Paper 450SQM/H Flatbed Inkjet Printer With 6 Printheads 4

450GSM Paper 450SQM/H Flatbed Inkjet Printer With 6 Printheads 5

450GSM Paper 450SQM/H Flatbed Inkjet Printer With 6 Printheads 6

450GSM Paper 450SQM/H Flatbed Inkjet Printer With 6 Printheads 7
