540mm Digital Book Newspaper Printing Width 100M/Min POD Inkjet Printer

1 set
540mm Digital Book Newspaper Printing Width 100M/Min POD Inkjet Printer
Features Gallery Product Description Request A Quote
Speed: 100 M/min
Max Printing Width: 540mm
Resolution: 600dpi*600dpi/2bit, 600dpi*1,200dpi/2bit
Printing Head: Kyocera
Application: Book Printing, Magazine Printing, Short Printing Jobs, Customized Job
Media Type: Offset Paper, Newspaper, Inkjet Coated Paper
High Light:

POD Thermal CTP Machine


100M/Min Thermal CTP Machine


540mm Printing Width CTP Machine

Basic Infomation
Place of Origin: CHINA
Brand Name: Ecoographix
Certification: ISO9000, ISO20001, CE
Model Number: P5600
Payment & Shipping Terms
Packaging Details: Wooden case
Delivery Time: 30 DAYS
Payment Terms: L/C, T/T
Supply Ability: 100 SETS PER YEAR
Product Description

More Affordable Inkjet POD Solution in the World!

• Market proved drop-on-demand industrial ink-jet head technology

• Total roll-to-sheet print-on-demand ink-jet print solution

• Short-run mono-color duplex or dual-color duplex book and periodical printing

• Flexible deployment of structure, easily expand to dual-color duplex or spot color

• Sales price competitivity as affordable as offset press


Core Technologies

• Inkjet printhead control

• Circulating ink supplying control

• Automatic printhead self-clean system

• Fast-speed paralleling RIP

• Variable data processing

• Special multiple grade-level FM screening for inkjet



• Practical printing speed: 99 m/min

• Power-on to ready time: <20 minutes

• Daily maintenance time: <20 minutes

• Daily running time: >20 hours

• 63,000 A4 prints per hour on average speed at 85 m/min

• Average sales: lower than laser and approaching to offset

• Competitive balance: 2,000-3,000 copies comparing to offset

Key features

• 64-bit system, more memory space, higher performance, up to 1,600 A4 prints per minute

• Independent and stable tension control, to avoid the damage of printhead caused by the moving paper in unstable tension

• Optimized structure of printhead module, to simplify the services of manufacture, installation and maintenance

• Re-designed and patented paper feeding route, to get to the root of the problem of hurting the printhead module caused by high temperature air while printing back face

• Implemented QR code to monitor the correction of whole job, including JobID, Copy#, Page#, Front/Back, etc.

• Re-designed drying system, narrow spectrum, to save power consumption by 50%

• Independent and centralized ink supplying cabin (from main press), easy to deploy and extend the ink supplying ability for more press

• Untouched self-clean system, longer life of printhead

• Remote diagnosis and license management via internet

• Support multiple languages: Chinese, English, Korean













540mm Digital Book Newspaper Printing Width 100M/Min POD Inkjet Printer 0

High-Speed Inkjet Digital Press
Model Ecoo-P5600 Ecoo-P4400
Inkjet head Drop-on-Demand Piezoelectric, powered by Kyocera
Resolution 600dpi*600dpi/2bit, 600dpi*1,200dpi/2bit (on half speed)
Max. printing speed 100m/min
Max. media width 560mm 440mm
Max. printing width 540mm 432mm
Printing mode Monochrome duplex(Pxx12), dual-color simplex(Pxx21); Dual-color duplex(Pxx22)
Media feeding mode Roll to roll, with inline buffer, cutter and stacker
Media thickness 45 gsm – 165 gsm
Media type Offset paper, newspaper, inkjet coated paper
Ink Water based pigment ink, dye ink
Dry method Infrared dryer (automatic adjustment on printing speed)
Digital front-end Founder EagleJet™inkjet imaging system (Windows Server based)
Optional Image inspection, folding (3rd party)
Operating environment Temperature: 22.5℃-27.5℃, humidity:40%-80%(air conditioning recommend )
AC power

Mechanical platform: 380 VAC / 15 KW max

Dryer system: 380 VAC / 1-35 KW

Controller system: 220 VAC / 6KW max

Installation space 16,400*5800*3000mm
