Digital 3D Printing Sand Mold Resin Printer 60L/H

1SET
MOQ
Negotiable
Price
Digital 3D Printing Sand Mold Resin Printer 60L/H
Features Gallery Product Description Request A Quote
Features
Specifications
Layer Thickness: 0.15-0.5mm
Build Speed: 25-60 L/h
Print Resolution: 600DPI
Machine Size: 5200 X 2200 X 3000(mm)
Weight: 2800KGS
Condition: New
Warranty: One Year
Payement Term: 30%deposit,70% Before Shipping
Highlight:

600dpi 3d Sand Printer

,

Sand Mold Resin Printer

,

60L/H 3D Sand Mold Printer

Basic Infomation
Place of Origin: CHINA
Brand Name: ECOOGRAPHIX
Certification: CE,SGS
Model Number: S800
Payment & Shipping Terms
Packaging Details: Standard export packing
Delivery Time: Within 20days
Payment Terms: T/T, L/C
Supply Ability: 300SETs
Product Description

S800 Digital Industrial 3D Printing Sand Mold Resin Printer





Features:

1) Tailor made for customer

Self- produced print head and electronic control drive system, available with 256, 512 series of print head for users to choose. To improve the printing efficiency, the quantity of print head, DPI resolution and size of ink droplet can be tailor-made according to the requirement of customer.



2) 1µm precision

The main motion framework adopts linear drive combination of linear motor and raster ruler. And the precision of raster ruler reaches up to 1µm, which reduces the volume of product and improves the reliability, speed and precision of motion.



3) 25 seconds/layer building speed

With 25 60Lh building speed, t0.3mm product accuracy and the printing time for one job box within 12+2 hours, the performance achieves the top level of international sand type 3D printer, and the sanding speed is higher than any product of the same model.



4) Consumables-free fresh sand processing system

Adopt CFD calculation method to optimize the sand processing system. which makes consumables like filter not be needed during sand processing, achieving energy conservation and emission reduction.



5) Steel frame

Adopt steel frame to make the overall rigidity, shake proof and fatigue life improve a lot, and the standalone electronic control cabinet brings faster disassembly, easier installation and maintenance.



Specification:









ECOO 3D Printer Machine Specifications

Model S800
Job Box Volume

Normal size: 800x500x400(160L)

Limited size: 900x600x400

Layer Thickness 0.15-0.5mm
Build Speed 25-60 L/h
Print Resolution 600DPI

Motion Control Accuracy ±3ᶣm
Product Accuracy ±0.03mm
Max Consumption 8KW
Consumable Sand, resin and curing agent
Customization Supported Supported
Demension 5200 x 2200 x 3000
Weight 2.8T


Hangzhou EcooGraphix Digital Technology Co, Ltd. Add: Room 708, Tianheng Building, No.1509, Binsheng Rd, Binjiang District, Hangzhou, China

Tel: 0086 571-87391001 Fax:0086 0571-87391001 E-mail:info@ecoographix.com Website: www.ecoographix.com
